DYNACORD 12“, 2-vägs, passiv, koaxial hornhögtalare, 8 ?/350 W RMS, 106 dB SPL 1W/1m, svart
The Dynacord FX12-PRO is a medium long throw mid/high- frequency cabinet in coaxial design. It can be used also without
subwoofer cabinets in high-quality sound reinforcement system for speech for medium-throw distances. The recommended active
x-over frequency is 140 Hz, 18 dB/oct. Butterworth. In the lo-mid range an ND 12 A Electro-Voice loudspeaker chassis works
into a conical horn. The 80x40 Constant Directivity horn, driven by an Electro-Voice 1.4" ND 6 neodymium driver delivers the
frequency range above 1kHz.
The FX12-PRO is equipped with a passive x-over (1kHz, 18 dB/oct). Every transducer is protected against thermal overload with
an electronic circuit called voice coil tracking protection. This circuit senses the terminal voltages of the transducers and
simulates the thermal behaviour of the transducers’ voice coils. In case of a potential thermal overload the power applied
to the speakers is reduced to a safe level. Power amps up to 1200W 8 Ohms can be used in order to have maximum dynamic range
without the danger of thermal overload in non-controlled situations. The voice coil tracking protection exhibits ‘soft’
switching characteristics, so no annoying clicks or pops are audible. The circuitry automatically resets after the voice coil
temperature has reached a safe value.
The cabinet features 6 flying points. With the flying bracket FB-FX12-PRO it can be easily hung on a truss and positioned to
cover the audience.
Neodymium ND6 driver
Neodymium ND12A mid transducer
Extremely high sensitivity, 106 dB SPL 1W/1m
Voice coil tracking protection
